CSO · 2627–0041
Tonight · 7:30 PM
Your evening begins here.
Saturday, October 18
Good evening, Renaise.
Tonight at Music Hall
Doors 6:30
CSO · 2627–0041
Your next action
ReadyFor members
2026–27 season
Events
CSO · 2627–0041
E
Tonight · 7:30 PM
Măcelaru conducts Enescu
Program
EnescuSymphony No. 3
RavelLa Valse
Tonight’s event
How are you entering?
No signal? Your pass and ticket remain available offline.
Member access
Subscription
CSO®
2026–27
Renaise Kim
Available offlineUpdated just now
Pass tools
Harmony member
Available now
Membership 1048
Profile
Renaise Kimrenaise@example.com
Member mobile app
Navigation architecture
Every solid node is a screen that exists in this prototype. Shared screens are reached from more than one destination. Roadmap items are drawn apart and dashed — they are not built.
Entry
Destination · bottom nav
Screen in prototype
Shared screen
Roadmap · not built
SplashYour evening begins here
Bottom navigation · four destinations, always present
Home
Announcements
Patron status
Mini profile cardcondensed patron record
Challengese.g. use three benefits this month
Your next action→ Member pass
Upcoming eventTonight’s feature → Event detail
Subscription snapshotFor members · 3 benefits · 2 events
Events
All / Your Eventssegmented control
Calendar
FiltersFor you · Classical · Pops
Event listThree dated rows → Event detail
Purchase links
Ticket + seat detail
View programmultimedia experience
Exchange tickets
Subscription
Membership cardMember pass · QR + NFC
Plan statusHarmony · member access
Included shows
Visible benefits→ Benefits
Renewal
Member connectscan card to link members
Profile
Patron identityMembership 1048
Patron stats
Season journey
Attendance history
Contribution history
HouseholdLinked accounts
Shareable profileengagement, not account
Achievementslater
Settings→ five controls
Contact information
Eligibilitywas: student verification
Notificationsexists · Notifications + Support
Accessibilityexists · Preferences + accessibility
Account controlsexists · Repair web session
Event detailFrom Home + Events · program, share, add to calendar
Choose accessFrom Event detail · member pass or event ticket
BenefitsFrom Home + Subscription · coat check, lounge, guest seat
Non-subscriber upsell
Marketing + promotions
Gamification hub
Sponsor rewards
Friend ticket + payment link
In-hall perk triggers
Live program bubble
First-download incentive
Venue perk activation
Member mobile app
About
What this prototype is, what it covers, and what it does not. Written from the build — every count below is read off the navigation map, not asserted.01 · The product
Maestro is a ticketing and patron-CRM platform for performing-arts organisations, sitting on top of Tessitura. This prototype covers the member-facing mobile app — the surface a subscriber uses between buying a ticket and walking into the hall.
It exists to answer one question ahead of build: what does a member actually do in an app like this, and in what order.
02 · What is here
Three working views, plus this one.
- Prototype — eight screens: splash, home, events, event detail, choose access, member pass, benefits, account. Four bottom-nav destinations.
- Navigation map — the target IA, with every node marked built or not built. Exportable as Markdown.
- Identity system — type, colour, photography, spacing, shape, icons, components, voice.
03 · Coverage
The IA is specified well ahead of the build. Against the five-section spec, 17 nodes exist and 30 do not.
Counting the three shared screens, which are real. The thin sections are Events — no calendar, purchase, seat detail or exchange — and Profile, where nearly everything outstanding is history and statistics. That second gap is not a design problem: attendance history, contribution history and season journey are data surfaces, and they need a source before they need a screen.
04 · Structural decisions
- Settings sits under Profile, not in the tab bar. Four destinations, not five.
- Profile is the patron record — stats, journey, attendance, contribution, household. Account controls moved out.
- Past events belong to Profile as statistics, not to Events.
- Three of the five Settings controls already exist. They were living in the wrong destination, so that work is a move rather than a build.
05 · Brand
Six flat colours, squared corners, two typefaces. Burgundy #390C0C marks the primary action; lemon #E1EFA3 is the only accent and is legal on burgundy or off-black only — on white it measures 1.23:1.
Radii are zero by direction. The Figma source carries 0, 2, 4 and 8 with no rule; the build resolves that to square.
Photography is the one place colour beyond the six enters the system, which is why six values are enough everywhere else.
06 · Known gaps
- Typefaces are unlicensed. FT System is a trial cut carrying 66 glyphs; Lab Grotesque arrived as desktop files. Two strings render mixed-font as a result: Măcelaru conducts Enescu and How are you entering?
- No conforming photography exists. The direction is motion blur; both images in the app are sharp. Section 05 of the identity system marks them as not meeting the brief.
- Two built nodes are disputed. A 2026-08-25 review found Your next action undefined and questioned whether Available offline earns its place. Both still show as built.
- No mobile type scale. The type variables were namespaced Desktop/ from the start; the mobile set was never drawn.
Identity system · 01
A program note that knows where your ticket is.
Headlines carry the expression. Everything a member has to read or tap stays plain.
Operating rules
FT System sets headlines only. Lab Grotesque sets everything else, including all UI. FT System carries 66 glyphs, so accents, dashes and question marks drop to Lab Grotesque mid-word.
Burgundy marks the primary action and the active tab. Lemon is legal on burgundy or off-black and nowhere else — on white it measures 1.23:1. The rest is gray.
A box means these things act together. Most lists are just lists.
Separation comes from a change of ground or a hairline. The one drop shadow in the build sits under the phone chassis; every other shadow is inset.
Type tokens
--display · FT System Blank
Maestro
--sans · Lab Grotesque
Member pass ready
Tonight · 7:30 PM · Music HallColor tokens
#FFFFFF#EAEAEA#101010#E1EFA3#C2ACE8#390C0CPhotography
Motion blur carries the energy of live performance and reveals the layers of movement inside it — the complexity behind a performance that Maestro brings into focus.
Spacing tokens
--space-14px--space-28px--space-416px--space-624px--space-1248pxShape tokens
--radius-tile0--radius-control0--radius-card0--radius-round50% · marks onlyIcon tokens
18px · 1.75 stroke Feather. Every icon has a label next to it.
Components
Live at Music HallNow
Voice
Doors open at 6:30.
Not “Your unforgettable evening awaits.” Say what the member needs.
